vanagon fuel injection

MS-700B v1.5 EFI Kit for stock 1.9 liter VW Waterboxer engine



1.8.24  v1.5 Current Lead time is 3-4 weeks.

The MS-700B kit is designed to be retro-fitted to a stock Volkswagen 1.9l  fuel-injected, waterboxer engines, in Vanagon applications. This kit requires no modification to your existing 1.9l componenets as this kit utilizes your complete stock 1.9 intake system.

 The MS-700B v1.5 replaces your existing Bosch “digifant” system with a modern, open source, speed-density ignition and fuel manage solution.  Unlike the Bosch solution, the MS-700B does not rely on an AFM to determine fuel deliver, a distributer and hall sensor to set spark timing or Bosch idle control electronics.

Performance improvements are immediately noticeable. The WBXr appears to come alive from idle to 5K.

The kit is equipped, with everything you need to complete the install.  Even better is that all the wear components are OEM off the shelf, available from your local auto parts store.  The MS-700B uses six sensors and robust open-source software to vastly improve power, drivability, reliability, efficiency, and emissions.  The wiring harness is hand assembled in the USA, assembled with OEM best practices and materials.  This includes proper harness management with Kapton tape used for branch circuit management, TESA 51036 tape as the outer covering, and AMP Bosch OEM style, crimped terminations for an engine bay application.  This piece of the kit is arguably the most important and a source of pride for MansiSpeed with each harness bench tested.

Installation is straight forward, and with basic mechanical aptitude, can be installed in 8 hours or less, depending on how much cleaning, painting or general “house keeping” you want to perform during the install.  All of the harness and connection work is contained to the original ECU location under the rear seat and the engine bay.

The MS-700B is part of a progressive, Mansispeed engine upgrade program.  The MS-700B works with Mansispeed’s  fuel injectors and 1.35 rockers and also manages the MS-800 Turbo kit with only a software upload.

The kits comes with installation instructions and easy start-up procedures.



Important Core Charge Information:

Purchase of the MS-700 requires a core commitment on your part. A core charge of $100.00 must be paid if you do not intend to return a usable 3 groove crankshaft pully.  Orders will not be shipped until either the cores are received or the core charge invoice of $100.00 has been paid.  This invoice will be prepared once your core selection and MS-700 EFI Kit purchase has been made.  Upon the receiving of your cores, you will be refunded the $100.00.   Cores must be received within 60 days of your order's ship date. You are responsible for the packaging and shipping fees of the core return.





MS-700 Kit includes:

  • Engine Control Unit (Microsquirt with bespoke programming by MansiSpeed)
  • Terminated Tested Wiring Loom
  • NEW MS-107 MansiSpeed Throttle Body with TPS modification
  • Modified Three Groove Crank Pully (CPS trigger ring)
  • MAP 1 Sensor (Primary Manifold Pressure) v1.5 installation
  • MAP2 Sensor (Atmospheric Pressure)
  • New Idle Control Valve with install kit: molded silicone hoses and ICV bracket
  • Crank Position Sensor with bespoke bracket (Timing and RPM)
  • Wide Band o2 Sensor with Spartan lambda Controller
  • Coil Pack Amplifier
  • 4 Coil on plug ignition coils with bracket retainers
  • Tachometer signal adapter (amplifies signal to Vanagon tachometer)
  • 4 new manifold runner boots with clamps 1.9l runner size
  • Fuel pressure regulator with bracket
  • Microsquirt data cable
  • USB 2.0 to Serial adapter cable (Downloadable Driver with CD)
  • 3.5 plug to serial cable CAN communication cable
  • AFM delete tube connecting stock 1.9l air filter box to throttle body boot
  • Distributor cap delete cover
  • MS-700 EFI Kit Core Requirements

    Important Core Charge Information:

    Purchase of the MS-700 v1.5 requires a core commitment on you, the customer. A core charge of $100.00 must be paid if you do not intend to return a usable 3 groove crankshaft pully.

    Orders will not be shipped until either the cores are received or the seperate core charge invoice of $100.00 has been paid.  This invoice will be prepared once your  MS-700 EFI Kit purchase has been received.  Upon the receiving of your cores, you will be refunded the $100.00.   Cores must be received within 60 days of your order's ship date. You are responsible for the packaging and shipping fees of the core return.

  • Tech Note MS-700-1 Pully Seal Surface

    Every kit comes with a modified crank pully, Each pull gets cleaned, prepped, machined for the trigger ring, tig wellded adn the sealling surface on the nose of the pully pollsihed.  While we work to make the pully "like new", it is not a new pully.  The paint may have a blemish or two, the paint is simply to slow down mother natures impact.  And there will be a tell tale sign of wear on the polished surface.  A ring will be seen and maybe even felt  (.002").  Be assured that even with a reasonably worn crank seal, it will not leak.  If you are concerned, go ahead and replace the seal with a new one.  We have measured the seals garter spring pressure on both new and almost worn out sealls and the wear groove presents negligible impact to the sealing ability.

  • Links to Unedited Product discussion and feedback

  • MS-700 V1.5 Update Notes 1.8.24

    V1.5 UPDATE:



    We are constanstantly making improvements to our porducts. The MS-700 is no exception.  In an effort to make installation easier, we have relocated the  MAP sensor. It was previosuly mounted to the manifold center section at a custom MansiSpeed modified mounting port. This required customers to send a manifold center section core to us as part of the core exchange. With v1.5, you no longer need to remove the manifold center section and the MAP and fuel pressure regulator components can be installed in the van.  Of course you may decide to remove and refurbish your center section with a fresh coat of paint and the componenets can then be installed on the bench too.  The Throttle Body and Pulley cores are still needed. We also will still provide new manifold runner boots as part of the kit and recommend replacement during your installation.

$2,849.00Price
